Bursting strength of a packaging material is a major indicator of its quality and strength. The manufacturers need to test this attribute of the packaging materials in order to provide the best quality of products supplied to the clients. The Bursting Strength Tester for UAE offered by Cell Instruments is widely used for accurate analysis of the bursting strength of the test specimen. The instrument is easy to operate and gives a high rate of accuracy and repeatability of the test procedure. The machine is best for international industries as it is in compliance with all the international quality standards.
Cell Instruments is a major manufacturer and supplier of Bursting Strength Tester for United Arab Emirates that is used for accurate evaluation of packaging materials such as corrugated sheets, fiber sheets, cardboards, fabrics and so forth. The instrument is loaded with a digital peak load indicator that displays highly accurate test results. It is also capable of storing nine peak hold values from previous test results for future reference. The machine is in compliance with different quality testing standards and is provided to the clients with an instruction guide and a calibration certificate.
Specification
| Item | ZNP-01 Paper Bursting Tester | BNP-01 Board Bursting Tester |
| Measurement Range | 70~1600kpa（paper） | 150 ~5600kpa （board） |
| Force Resolution | 1/100000 | |
| Data Analysis Sampling | Sampling Frequency) 400 times/second | |
| Force Accuracy | ±0.1% (20~100% Full Scale) | |
| Accuracy | ≤±0.5% | |
| Resolution | 0.01kpa | |
| Deformation Error | ≤1mm | |
| Concentricity of Upper and Lower Plates | ≤0.25mm | |
| Diaphragm Resistance | (9±0.2)mm/（30±5)kPa | |
| Oil Feeding Speed | 95±5ml/min（paper） | 175±5ml/min(board) |
| Platen Diameter | Upper：30.5±0.1mm ; | Upper：31.5±0.1mm ; |
| Lower：33.1±0.1mm（paper） | Lower：31.5±0.1mm（board） | |
| Air Source | 0.6~0.7Mpa | |
| Display | 5in Touch Screen | |
| Testing Control | Equipped with delayed pressurization control and pressure release delay control. | |
| Clamping Force | Adjustable pressure range from 100kPa to 1200kPa with a stabilizing function to ensure consistent clamping force. | |
| Oil Cup System | High-Strength High-Pressure Oil Circuit Sealing System with Dual Sealing Knobs, (25mm High-Pressure 304 Stainless Steel Oil Pipe | |
| Circuit Board Chip Protection | Equipped with a built-in water vapor filtration device to ensure the stability of the circuit. | |
| Calibration System | Includes a built-in calibration system and a self-contained manual pressure and pressure release control system. | |
| Material of Testing Head | The oil cylinder section, upper clamping, and lower clamping parts are all made of 304 stainless steel. | |
| Safety Devices | Comes with a protective cover and a power supply anti-interference protection module. | |
| Language Switching | Allows for free switching between Chinese and English languages. | |
| Unit Conversion | Kg/cm2、kpa、lbf/in2 | |
| Print Output | Modular Integrated Thermal Printer | |
- Related Standards: ASTM D 3786 / D 3786 M – 13, BS 3137, ISO 2758, ISO 3303-1:2012, ISO 3689-1983, IS – 1060, 1987
Features
- The apparatus is equipped with a highly efficient digital display.
- The machine is given with a clamping mechanism that is manually operated.
- The peak load indicator has a capacity of storing the test values from last nine test procedures.
