The lab testing machine is designed keeping in mind various standard test methods and is widely recommended for plastic and paper and packaging industries.
Cell Instruments’s Bond Strength Tester is the best and high-quality testing machine which is capable of peeling the laminated and self-adhesive materials from an angle of 180o with the rate of 300mm per minute. The instrument offers the accuracy of +/- 2%. Cell Instruments Stantest offers a table top model with the facility of calibration. The device is easy to operate. It is designed with two jaws to clamp the sample of the adhesive to measure its bond strength when they move in opposite direction.
Moreover, the peel adhesion fixture can also be set at an angle of 90o that helps to evaluate the response of the laminates and self-adhesive materials. The testing instrument is built on the rigid metallic base plate that ensures the stability of the device. Cell Instruments Stantest also manufactures the range of Bond Strength tester for the manufacturers of Nigeria, Bangladesh, Bahrain, Indonesia, Thailand, Sri Lanka, UAE, and Zambia so the manufacturers in these countries can also measure the quality of their packaging product.
Specification
- Load Cell Capacity: 20 Kgf
- Least Count/Resolution: 0.020 kgf
- Power: 220V, 50 Hz
- Speed: 300 mm/min ± 5%
- Standards: ASTM D903
Features
- Microprocessor based display for accurate test results
- Print out facility is optional.
- Display for Peel Adhesive strength of test specimen
- Memory to hold up to 9 test reading
- Highly accurate test results under elongation force
- Strong gripping clamps to perform Peel test at 180 degree.
- Feather touch controls
- Optional: Seal Strength can also be tested using a 90-degree test fixture.
